Wineo Organic Flooring - PURLINE 1000 wood XL Noble Oak Chocolate (PLC312R)

32 Commercial (moderate) - PVC free design flooring - Beveled edge (4 sides) - Wood effect - Plank pattern - brown

Item no.: PLC312R

Ecological floor covering.
Without chlorine and harmful softeners.
Made from renewable raw materials.
Awarded the Blue Angel.

Offer request

Description

Technical data

DIY - Videos

Product description

Ecological floor covering.
Without chlorine and harmful softeners.
Made from renewable raw materials.
Awarded the Blue Angel.

Wineo 1000 is the ecological flooring for a homely and healthy home. It meets your requirements for smart and healthy living right down the line.

Environmentally conscious and ecological organic flooring
Dimensionally stable thanks to Fleece TEC system
Easy cleaning and maintenance

wineo

As a brand of the internationally active company Windmöller, wineo operates in over 70 countries with quality floors for a wide range of applications. Originally created through the merger of the family-owned companies Windmöller and Witex, the East Westphalian group based in Augustdorf has been operating under the Wineo name since 2013. The sustainably produced floor coverings from Wineo feature the "Made in Germany" seal of quality and provide the optimum flooring solution for private areas, public facilities and light industry. All wineo products undergo a 7-fold quality control and meet the highest standards. The 3rd generation family business is aware of its high social and ecological responsibility and has been focusing on environmentally compliant product design for years.

item no.: PLC312R

sustainable
resilient
healthy to live with
Blue Angel

Technical data

item no.	PLC312R
Structure	PVC free design flooring
Installation type	click
installation pattern	Plank pattern (1-plank)
Sorting (grain)	lively/rustic
Joint	Beveled edge (4 sides)
Underfloor heating	suitable
Slip resistance	R9
Wear class	32 Commercial (moderate)
Click system	FoldDown
Weight	20.6460 kg / Packing
Manufacturer	Wineo
Colour	brown
EAN	4017268423638
Piece per package	6
Collection	PURLINE 1000
Collection variant	wood XL
suitable for	Bath, Kitchen, Bedroom & living room, Hallway & Corridor
Look	Wood effect
Range of application	Residential, Commercial
Length in mm	1507
Width in mm	246
Thickness in mm	5
Warranty	10 Jahre Privat
Shipping group	L
Click variant	DropDown
Package Content	2,22 m²

Downloads

Print page

DIY step by step

Variant: DIY-Instruction

button

1. substrate preparation

Check the subfloor. Any unevenness exceeding 3mm should be sanded down or filled with a floor levelling compound. Then clean the surface to be laid with a hoover.

CAUTION: Never install vinyl over a soft subfloor such as carpet, cork or any type of foam underlay.

button

2. acclimatisation

The vinyl planks should be stored horizontally in the room where it is to be installed for at least 48 hours before the installation in the packages. This will allow the material to acclimatise to the room temperature and not "work" so hard after installation.

button

3. before laying

Before laying the floor, it is imperative to follow the official laying instructions, which are included in every package, otherwise any claim to warranty and guarantee will be void!

Before laying out the floor, check the wall you are starting on and make sure it is at right angles to the opposite wall. If the impact sound insulation is not already integrated, we now recommend spreading out the insulation.

button

4. laying instructions

Tips on the drop-down click system: In order to achieve the most uniform appearance of the floor, it is advisable to install panels from different packages mixed together. You should start laying in one corner (left) and starting from the wall. Lay the first plank with the tongue side facing the wall. Then snap the second plank into the first from the top on the face side. In the second row, place the plank at an angle to the long side of the row already laid and fold it down. With the help of a rubber mallet, you can lock the face of the following planks by gently hitting them. To cut a plank, now take measurements and mark the plank. Then take an angle and tear and break the plank with a multi-purpose knife/cutter.

button

5. finishing the last row

The last plank of a row should be the same length as the first plank. Place the spacers against walls, door frames, fixed wall cabinets, kitchen units etc. so that you have an expansion gap of approx. 5-10mm for underfloor movement or expansion of the product. To install the last row, it is recommended to use the floor layer's jointing iron from the accessories. When using skirting boards, make sure that the expansion joint is covered by the skirting board. If the floor is sealed, e.g. in the bathroom, the PE round cord is now inserted into the expansion joint and the floor sealed with a silicone joint.

button

6. attach skirting boards

Finally, cut off the PU film approx. 2 cm high and attach the skirting boards.
